Rectangular Connectors - Headers, Receptacles, Female Sockets
CONN RCPT 42POS 0.079 GOLD SMD
  • Код виробника: CLT-121-02-F-D-BE-A-K-TR
  • Виробник: Samtec Inc.
  • Код: CLT-121-02-F-D-BE-A-K-TR-ND
  • Інформація: CONN RCPT 42POS 0.079 GOLD SMD
Безкоштовна доставка
Характеристики
42 Position Receptacle, Bottom Entry Connector 0.079" (2.00mm) Surface Mount Gold
  • Base Part Number: CLT-121
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Connector Type: Receptacle, Bottom Entry
  • Contact Type: Female Socket
  • Style: Board to Board
  • Number of Positions: 42
  • Number of Positions Loaded: All
  • Pitch - Mating: 0.079" (2.00mm)
  • Number of Rows: 2
  • Row Spacing - Mating: 0.079" (2.00mm)
  • Mounting Type: Surface Mount
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Contact Finish - Mating: Gold
  • Contact Finish Thickness - Mating: 3.00µin (0.076µm)
  • Insulation Color: Black
  • Insulation Height: 0.083" (2.10mm)
  • Operating Temperature: -55°C ~ 125°C
  • Material Flammability Rating: UL94 V-0
  • Contact Finish - Post: Tin
  • Features: Board Guide, Pick and Place
  • Current Rating (Amps): 4.1A per Contact
  • Insulation Material: Liquid Crystal Polymer (LCP)
  • Contact Shape: Square
  • Contact Material: Phosphor Bronze
  • Manufacturer: Samtec Inc.
digikey
Доступно штук: 0
Термін поставки: Доставка протягом 3....6 тижднів
Мімнімальне замовлення: 1450 шт.
Кількість Ціна, грн з ПДВ
1450+ 205,915 грн
