CONN RCPT 42POS 0.079 GOLD SMD
- Код виробника: CLT-121-02-L-D-BE-A
- Виробник: Samtec Inc.
- Код: CLT-121-02-L-D-BE-A-ND
- Інформація: CONN RCPT 42POS 0.079 GOLD SMD
Безкоштовна доставка
Характеристики
42 Position Receptacle, Bottom Entry Connector 0.079" (2.00mm) Surface Mount Gold
- Base Part Number: CLT-121
- Packaging: Tube
- Part Status: Active
- Connector Type: Receptacle, Bottom Entry
- Contact Type: Female Socket
- Style: Board to Board
- Number of Positions: 42
- Number of Positions Loaded: All
- Pitch - Mating: 0.079" (2.00mm)
- Number of Rows: 2
- Row Spacing - Mating: 0.079" (2.00mm)
- Mounting Type: Surface Mount
- Termination: Solder
- Fastening Type: Push-Pull
- Contact Finish - Mating: Gold
- Contact Finish Thickness - Mating: 10.0µin (0.25µm)
- Insulation Color: Black
- Insulation Height: 0.083" (2.10mm)
- Operating Temperature: -55°C ~ 125°C
- Material Flammability Rating: UL94 V-0
- Contact Finish - Post: Tin
- Features: Board Guide
- Current Rating (Amps): 4.1A per Contact
- Insulation Material: Liquid Crystal Polymer (LCP)
- Contact Shape: Square
- Contact Material: Phosphor Bronze
- Manufacturer: Samtec Inc.
digikey
Доступно штук: 0
Термін поставки: Доставка протягом 3....6 тижднів
Мімнімальне замовлення: 13 шт.
| Кількість | Ціна, грн з ПДВ |
| 13+ | 595,441 грн |
